D-01 children’s rehabilitation bed

D-01 children’s rehabilitation bed intended for paediatric hospital wards

  • Description
  • Size Guide

Description

Description

  • Bed structure made of powder-coated steel profiles
  • Two-segment mattress frame
  • Mattress frame segments with powder-coated metal mesh
  • Back segment adjustment up to 60°
  • The bed is equipped with lowered side rails with locks preventing accidental opening. The locks are located in side rails and are easy to use
  • Side rail height adjustment 915-1315 mm
  • Trendelenburg and reverse Trendelenburg positions
  • The bed is fitted with 4 wheels with 125 mm in diameter, including 2 wheels with individual movement and turning locks
  • Mattress frame regulation with a hook mechanism

Wyposażenie dodatkowe

  • Side rails folded along the mattress frame
  • Hospital mattress SI .CH
  • Drip rack with 2 or 4 hooks
  • Frame for patient file with hidden personal information

Technical data

  • Total width 765 mm ± 10mm
  • Total length: 1600mm ± 10mm
  • Mattress frame height from floor level adjustable, 505-805 mm;
  • Trendelenburg and reverse Trendelenburg positions 0-15°
  • Additional equipment
  • Hospital mattress SI .CH
  • Bedside drip rack
  • Double pull-up frame
  • Basket for personal belongings hung under the bed frame

Colours

  • Metal colours
  • RAL 7035
  • RAL 9006
  • RAL 9007
  • RAL 1015
  • RAL 5024
  • RAL 9005
  • RAL 9016
  • RAL 6018
  • RAL 1003
  • RAL 3002
  • Laminated board
  • Mountain alder
  • Bavaria beech
  • Cream
  • Water blue
  • Lime
  • Milano Yellow
  • Orange
  • White
  • Rotomulding
  • Gray
  • Blue
  • Beige



  • HPL
  • Gray
  • Bavaria beech
  • White
  • Water Blue
  • Cream
