A-63S/T hospital rehabilitation bed with wooden frame

The bed is intended for treatment and care at rehabilitation units, cardiac care units, for long term care and in nursing homes. Four-segment mattress frame with the adjustment of segments with electrical actuators controlled with a remote control.

  • Description
  • Size Guide

Description

Description

  • electrical adjustment of height and individual segments by a wired control
  • lowerleg segment adjustment with a ratchet mechanism
  • electrical Trendelenburg and reverse Trendelenburg functions
  • mattress frame segments with permanently fixed metal mesh (optional removable mesh, optional segments filled with HPL board, radiolucent)
  • head and foor boards made of solid wood and laminated board
  • wooden side rails with the possibility to lower and dismount without tools
  • 4 casters, diameter 125 mm, with brakes
  • autocontour
  • autoregression of the backrest segment (optional)
  • sleeves for mounting a pull up rail or drip rack
  • bumper disks (optional)
  • pull-out shelf for bed sheets (option)
  • central control panel (option)

Additional equipment

  • anti-bedsore mattress S.CH
  • hospital mattress S1.CH
  • pull-up rail
  • drip rack with 2 or 4 hooks
  • urine pot mount
  • bedpan mount
  • pull-out shelf for bed sheets
  • frame for patient file with hidden personal information

Technical data

  • Total width: 1040mm ±10mm
  • Total length ca. 2080mm ±10mm
  • Mattress frame dimensions 2000x900mm ±10mm
  • Height adjustment 400-840mm ±5mm
  • Backrest segment adjustment 0-70° (±5°)
  • Upper leg adjustment up to 35° (±5°)
  • Trendelenburg inclination 0-15° (±2°)
  • Reverse Trendelenburg inclination 0-16° (±2°)
  • Power ~230V, 50Hz
  • Protection class II type B

Colours

  • Metal colours
  • RAL 7035
  • RAL 9006
  • RAL 9007
  • RAL 1015
  • RAL 5024
  • RAL 9005
  • RAL 9016
  • RAL 6018
  • RAL 1003
  • RAL 3002
  • Laminated board
  • Mountain alder
  • Bavaria beech
  • Cream
  • Water blue
  • Lime
  • Milano Yellow
  • Orange
  • White




Attention
Standard colour for wooden elements is Bavaria Beech.
Rest of the colours are available only in quantity over 50 or after agreement with Sales Department.
